| Plaats van herkomst: | Shenzhen in China |
| Merknaam: | SCXK |
| Certificering: | CE/ROHS/FCC/ISO/CB |
| Modelnummer: | P10 |
| Min. bestelaantal: | Geen limiet |
|---|---|
| Prijs: | Onderhandelbaar |
| Verpakking Details: | Vluchtcase, houten kast, doos, het is aan jou. |
| Levertijd: | 7-10 werkdagen na ontvangst van uw betaling |
| Betalingscondities: | T/T, Western Union |
| Levering vermogen: | 5000 m² per maand |
| Pixelveld: | 10 mm | Buisschipkleur: | Volle kleur |
|---|---|---|---|
| LED -type: | SMD 3535 | Weergave -functie: | Video/tekst/afbeelding |
| Kabinetsmateriaal: | Ijzer | Framefrequentie: | > = 60Hz |
| Gemiddeld geen mislukking: | > = 1000 uur | Transmissafstand: | Internetkabel <100m |
| Vernieuw tarief: | > = 1920Hz | Stroomvoorziening: | AC80-260V±10%/50Hz,60Hz |
| Markeren: | SMD IP65 outdoor LED display,P10 full color LED billboard,building advertising LED screen |
||
SMD IP65 Outdoor Full Color LED Display Screen P8 P10 Building Advertising LED Billboard
| Parameter | Specification |
|---|---|
| Resolution/mm | 10 |
| Pixel configuration | 1R1G1B |
| Pixel density/pixels/m² | 10000m2 |
| Module resolution | 32*16 |
| Module size/mm | 320*160 |
| View distance | 10-300m |
| Single point brightness adjust | Can be added |
| Single point color adjust | Can be added |
| White balance brightness | >5000cd/㎡ |
| Color temperature | 6500K-9500K |
| Horizontal view angle | 120(degrees) |
| Vertical view angle | 60(degrees) |
| Signal Process bit | 10 or 16bit |
| Driving mode | Constant driving current |
| Scanning mode | static dring |
| Frame rate | 60Hz |
| Refresh frequency | 3000Hz |
| Control mode | Computer synchronous |
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted 255 steps. No grey loss |
| Out of control point | <1/10000 |
| Working hours | >72hours |
| Mean time Between Failure | >500hours |
| life time | >100000hours |
| Envirornment temperature range | operating temperature range -200c-500c |
| Maximun power :/m2 | <800w |
| Average power:/m2 | <300w |
| Self-check technolog | LEDspot self-check,communication check,power check,temperature monitor(need customization) |
| Remote monitoring | Remote supervision and control,record potential fault send out warning signs to the operators(need customization) |
| Software environment | windows NT,Windows 1999,Windows XP |
| Input power cable | AC110v to220v |
| Signal input | DVI |
| Warranty | 2years quality warranty ,10 years spare parts support |
To be the premier provider of creative, marketing and innovative solutions devoted to helping other companies succeed and grow.
Packing: wooden case, flight case for choose
Shipping: by air, sea, train, DHL, you are the boss
