Plaats van herkomst: | China |
Merknaam: | SCXK |
Certificering: | CE/ROHS/FCC/ISO/UL |
Modelnummer: | P3.91 |
Min. bestelaantal: | sqm 10 |
---|---|
Prijs: | negotiation |
Verpakking Details: | het triplexgeval, vluchtgeval, u kiest van wat u houdt. |
Levertijd: | 7-15 werkdagen |
Betalingscondities: | T/T, Western Union, MoneyGram |
Levering vermogen: | 5000sqm per maand |
Toepassing: | LEIDENE vertoning | Kleur:: | Volledige Kleur |
---|---|---|---|
Comité grootte:: | 250x250mm | Pixelhoogte:: | 3.91 |
Moduleresolutie:: | 64*64dots | Leiden:: | SMD1921 |
De gegevens zetten om:: | HUB75 | Aandrijvingswijze:: | 1/16 aftasten constante stroom |
Ingevoerd voltage:: | DC5V | machtsinput:: | 40W (200W-voeding voor 4pcs-paneel) |
Vernieuwingsfrequentie:: | 3840Hz | ||
Hoog licht: | SMD1921 huur LEIDENE Videomuur,P3.91 Huur Geleide Videomuur,40W maak de LEIDENE Reclameschermen waterdicht |
Features
1.Standard dimension module size 250mm×250mm,cabine size 500mm×500mm,Compatible model PH3.91/PH4.81/PH5.95 and other pixel Pitch standard size cabinet design.
2.High-precision die-cast aluminum cabinet, seamless unit box,Perfect solution for both outdoor using
3.Light and strong cabinet design with quick locate handle lock canbe quickly and easily assembled in various ways, it can be used ina variety of occasions ,to meet different customer requirement for a variety of applications.
4.140-degree viewing angle assure the screen has wider view area, meet various rent environment and requirements.
5.Sophisticated materials for led lamp and IC, uniform screen, real andnatural color, high grey scale, high refresh rate to ensure the amazing photographic effects.
Module Parameter:
Pixel pitch | 3.91mm |
Pixel configuration | 1R1G1B |
LED type | 3-in-1 SMD 2121 |
Module size | 250x250mm |
Module weight | 0.35kg |
Module resolution | 64x64dots |
Module quantity per cabinet | 4pcs |
Cabinet Parameter:
Cabinet size | 500x500mm |
Cabinet material | die- casting aluminum |
Cabinet weight | 6.5kg |
Cabinet resolution | 128x128 dots |
Ingress protection | Front/Rear IP65/IP54 |
Whole Screen Parameter
Pixel density | 65410dots/m² |
Brightness | ≥1200 cd/m² |
Viewing angle | H≥120° V≥120° |
Min.viewing distance | 3.9m |
Max.power consumption | 890W/m² |
Avg.power consumption | 330 W/m² |
Working voltage | 110~220VAC±15% |
Interface | HUB75 |
Colors | 16.7millon colors |
Gray level | 65536 |
Refresh rate | ≥1920Hz |
MTBF | ≥50000 hours |
Lifespan | ≥100000 hours |
Operating temperature | -10℃ ~ +60℃ |
Storage temperature | -20℃ ~ +60℃ |
Control System Parameter:
Video signal (with video processor) | AV, S-video,VGA, DVI, YPbPr, HDMI, SDI, DP |
Color temperature | Adjustable by software |
Brightness level | 256 levels, automatic adjustment by software |
Control way | Computer, video-synchronous, real-time, off-line, internet etc. |
Pixel Pitch: | 3.91 mm |
Pixel Configuration: | SMD2121 1R1G1B 3 in 1 |
Pixel density: | 65536 dots/m2 |
Driving method: | real 1/16 scan |
Viewing angle: | 140°V and 140°H |
Brightness: | 1000 nits(cd/m²) |
power consumption: | average 250 w/m2, max 600 w/m2 |
Cabinet Material: | Aluminum |
Cabinet weight: | Aluminium 7.5kg |
Standard Module size: | 250mm×250mm |
Standard Cabinet Size for option: | 500X500mm |
Working and Storage Humidity: | 20-60% RH |
Working Voltage: | AC 110v-220v ±10% 50-60Hz |
Processing: | 14bit-16bit |
Refresh Rate: | >3840Hz |
Working temperature: | -20°C-+60°C |
Application: | indoor use |
IP Rating: | IP30 |
A:LED Type is the description of LED lamp, for instance, the brand, the shape in physical, the size of the lamp, etc.
Module size is the measurement of a module.
Module resolution is the number of pixels per module.
A: Yes, we offer 2-5 years warranty to our products.
